Beckhoff ZK4800-8004-0100 Motor Cable
Nouveau
En stock2 unitésPrêt à être expédié
BECKHOFF ZK4800-8004-0100 Motor Connection Cable Industrial motor connection cable featuring a 10 m length, M23 SpeedTec connector system, PVC jacket, and compatibility with BECKHOFF AM8000 motors and AX8118 drive systems for fixed installation applications.
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
| Part No. | 148469 |
| Cable length | 10 m |
| Connector 1 | 9-Pins |Female |
| Connector 2 | 4- Wires / Male |
| Cable information | (2x22AWG)/C C E170315 c9dus AWM STYLE |
| Motor cables USED for | motors with M23 speedtec@plug system at AX8118 |
| Installation size, Head A | M23 |
| Connector type, Head A | plug |
| Contact type, Head A | female |
| Number of positions (face), Head A | Power: 3+PE, Signal: 5 |
| Mating cycles, Head A | 500 |
| Wire termination, Head A | crimp connection |
| Installation size, Head B | Pitch dimension 7.62 mm |
| Connector type, Head B | plug |
| Contact type, Head B | female |
| Number of positions (face), Head B | 4-pin |
| Mating cycles, Head B | 25 |
| Wire termination | Push-in |
| Use | fixed installation |
| Material jacket | PVC (polyvinyl chloride) |
| Outer cable diameter | 13.8 mm ± 0,4 mm |
| Min. bending radius, fixed installation | 5 x outer cable diameter |
| Suitable for | AM8x4x up to AM8x6x (up to winding code P),AL8000,ALxxxx at AL2250-0002,AX8118 |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1099455 |
| Weight | 3,14 |
