B&R X67DM1321 DIGITAL MIXED I/O MODULE
Module E/S mixte numérique B&R X67DM1321 module E/S industriel mixte numérique avec 8 canaux, fonctionnement 24 VDC et indice de protection IP67. Conçu pour une automatisation fiable au niveau du terrain dans des environnements industriels difficiles. Recommandation : Une solution fiable pour les systèmes de contrôle industriel distribués nécessitant une performance E/S durable classée IP67.
B&R X67DM1321 Digital Mixed I/O Module
The B&R X67DM1321 Digital Mixed I/O Module is a robust field-level automation module designed for reliable operation in harsh industrial environments. As part of the B&R X67 Series, this module provides flexible digital input and output functionality with advanced diagnostic and measurement capabilities, making it suitable for demanding automation and control applications.
Manufacturer: B&R
Type: Digital Mixed I/O Module
Model: X67DM1321
Revision: L0
Ean. No.: 48810218276
Series: X67
Additional Functions
Certifications And Standards
| Designed For | Field-level use in harsh industrial environment |
| Channels | 8 Digital I/O Channels |
| Voltage | Rated at 24 VDC (Operating Range 18 to 30 VDC) |
| Output Current | 0.5 A Per Channel; 4 A Total Nominal Current For The Module |
| Protection Rating | IP67 |
| Event Counters | 2 Event Counters With Frequency Up To 50 kHz |
| Gate Time Measurement | 1 Measurement Channel |
| Diagnostics | Configurable Input Filter And Single-Channel Output Diagnostics |
| Certificate | I1 3G EEx nA ILT5, TUV 05 ATEX 7201 |
| Standard | EX, cURus |
| Protection Degree | IP67 |
| Ambient Temperature | 0 To 60°C |
| Recommendation | Ideal for industrial automation systems requiring reliable distributed I/O control with high environmental protection and advanced signal processing capabilities. |
