Festo 153417 Push-IN L-Fitting Rotatable
Nouveau
En stock15 unitésPrêt à être expédié
Push-In L-Fitting Rotatable FESTO QSRL-3/8-12 rotatable pneumatic push-in L-fitting with R3/8 male thread connection, 12 mm tubing support, and durable PBT construction for industrial compressed air and water applications.
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
| Part No. | 153417 |
| Series | QSRL |
| Fluid | Compressed Air / Water (Liquid, Ice-Free) |
| Design | L-Shape Push-Pull Principle |
| Nominal Size | 7.4 mm |
| Operating Pressure | -0.95 ... 6 bar / -0.095 ... 1.4 MPa |
| Water Pressure Max. | 0.6 MPa |
| Tubing Insertion Depth | 23.5 mm |
| Rotational Speed Max. | 250 rpm |
| Pneumatic Connection, Port 1 | Male Thread R3/8 |
| Pneumatic Connection, Port 2 | For Tubing Outer Diameter Of 12 mm |
| Material | PBT |
| Ambient Temperature | 0 ... 60 °C |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1102230 |
| Weight | 0,08 |
