Montech DAPI-1 Rotary Unit
Nouveau
En stock1 unitéPrêt à être expédié
Rotary Unit Pneumatic MONTECH rotary unit designed for precise rotational movement, smooth operation, and reliable performance in industrial automation applications.
ActuatorAirAutomationComponentsControlCylinderDriveIndustrialMontechMotionPneumaticPneumaticsPositioningRotaryUUnit
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
| Part No. | 44905 |
| Driving Medium | Air, Oiled Or Unoiled, Filtered To 5 µm |
| Range of Adjustment of Angle of Rotation | 0 … 180° |
| Piston Diameter | 20 mm |
| Permissible Axial Load Tension/Compression | 90/120 N |
| Permissible Moment of Inertia | 40 kgcm² |
| Operating Pressure | 2 … 6 bar |
| End Stop Absorption Hydraulic Shock-Absorbers | Switching Points |
| Permissible Shaft Load | 5 Nm |
| Pneumatic Connection | Hose Dia. 4 mm |
| Material | Aluminum, Steel, Bronze, Plastics |
| Ambient Temperature | 10 … 50 °C |
| Dimensions | 154 x 40 x 73 mm |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1102051 |
| Weight | 0,76 |
