Omron E2S-Q23 Inductive Sensor
Nouveau
En stock1 unitéPrêt à être expédié
Inductive Proximity Sensor Compact OMRON inductive proximity sensor with 2.5 mm sensing distance, NPN normally open output, and IP67 protection for industrial automation applications.
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
| Series | E2S |
| Ref No | 14910M, 4 536854 841767 |
| Sensing direction | End face sensing |
| Size and sensing distance | 8x8mm,2.5mm(iron) |
| Electrical Design | NPN |
| Switching Output | Normally open |
| Sensing distance | 2.5mm |
| Setting distance | 0 to 1.9mm |
| Differential travel | 10% max.of sensing distance |
| Sensing object | Ferrous metal (refer toEngineeringDatafornon--ferrousmetal) |
| Standard sensing object | Iron,15x15x1mm |
| Supply voltage | 12to24VDC |
| Degree of protection | IEC60529, IP67 |
| Connection method | Pre--wired(standard length:1m) |
| Circuit protection | Reverse polarity connection and surge absorber |
| Ambient temperature Operating | -25 to 70C |
| Material Case | Polyallylate resin. |
| Stock key | CON003 |
| Condition | New |
| SKU | 1100914 |
| Weight | 0,02 |
