Pepperl+Fuchs KFU8-UFC-EX1.D Frequency Converter With Trip Value
299,99$
CONVERTISSEUR DE FRÉQUENCE Pepperl+Fuchs KFU8-UFC-EX1.D Convertisseur de fréquence avec valeur de déclenchement, entrée numérique, plage large 20 / 90 VDC / 48 / 253 VAC, sorties multiples et protection IP20 pour applications industrielles.
PEPPERL+FUCHS KFU8-UFC-EX1.D FREQUENCY CONVERTER WITH TRIP VALUE
The Pepperl+Fuchs KFU8-UFC-EX1.D is a reliable frequency converter with trip value, designed for precise signal processing in industrial automation. It features digital input compatibility, wide voltage range, and robust output connections, ensuring dependable operation in demanding environments.
Manufacturer: Pepperl+Fuchs
Type: Frequency Converter With Trip Value
Model: KFU8-UFC-EX1.D
Part No.: 231197
Signal Type: Digital Input
Input (Field Side):
Output (Control Side):
| Supply | Connection terminals 23, 24 |
| Rated Voltage | 20 / 90 VDC / 48 / 253 VAC |
| Frequency | 50 / 60 Hz |
| Power Dissipation / Consumption | ‰¤ 2 W; 2.5 VA / 2.2 W; 3 VA |
| Input I (intrinsically safe) | terminals 1+, 3- |
| Input II (non-intrinsically safe) | terminals 13+, 14- |
| Input I Frequency | 0.001 / 5000 Hz |
| Input II Open Circuit Voltage / Short-Circuit Current | 18 V / 5 mA |
| Output I | terminals 10, 11, 12 |
| Output II | terminals 16, 17, 18 |
| Output III | terminals 19+, 20- |
| Output IV | terminals 8+, 7- |
| Ambient Temperature | -20 / 60 °C |
| Connection | Screw terminals |
| Dimensions | 40 x 119 x 115 mm |
| Degree of Protection | IP20 |
