Pilz Pnoz XV2 3/24VDC 2N/O 2N/O T 774502 172436 Safety Relay
Utilisé
En stock3 unitésPrêt à être expédié
200,00$
Relais de sécurité Pilz PNOZXV23/24VDC2N/O2N/OT avec alimentation 24 V DC, 2 contacts de sécurité instantanés et 2 contacts de sécurité temporisés, conçu pour la surveillance de porte de sécurité et E-STOP.
AutomationComponentControlDeviceE-StopElectricalEquipmentGateIndustrialMachineMonitorPilzRelaySafety
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
Pilz PNOZXV23/24VDC2N/O2N/OT Safety Relay
The Pilz PNOZXV23/24VDC2N/O2N/OT Safety Relay, with ID No. 774502 172436, is a versatile safety solution designed for various industrial safety applications.
Application Options: Safety gate monitoring, Instantaneous E-STOP monitoring, Limit switch, Delayed E-STOP monitoring
- Manufacturer: Pilz
- Type: Safety Relay
- Model: PNOZXV23/24VDC2N/O2N/OT
- ID No.: 774502 172436
- Supply Voltage: 24 V DC
- Power Consumption: 4.5 W
- Number of Instantaneous Safety Contacts: 2
- Number of Delayed Safety Contacts: 2
- Contact Rating: 230 V AC, 5 A / 240 V AC, 8 A / 24 V DC, 7/8 A
- Fuse: 10 AF / 6 AT
- Terminal Style: Fixed
- Terminal Type: Screw Terminal
- Standards: EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1
- Max. Current at DC13 (6 cycles/min): 7.0 A
- Max. Current at AC15: 5.0 A
- Time: 3s
- Operating Temperature: -10 / 55 °C
- Dimensions: 45 x 87 x 121 mm
With its robust design and advanced safety features, the Pilz PNOZXV23/24VDC2N/O2N/OT Safety Relay is the ideal choice for ensuring safety compliance in demanding industrial applications.
