Raychem AT-TS-14 Surface Sensing Thermostat

Manufacturer: RAYCHEM
Type: Surface Sensing Thermostat
Model: ATTS14

Adjustable Sensing Temperature Range: 0 … 120 °C
Rated Supply Voltage: 230 V AC
Rated Switching Current Max.: 16 A
Frequency: 50 … 60 Hz
Contact: SPST Normally Open (NO)
Mounting: SB-110 and SB-111 or Surface Mount
Material: ABS
Protection Class: IP65 According to EN 60529
Temperature: -20 … 50 °C
Dimensions: 120 x 122 x 55 mm

Sensor Type: PTC KTY 83-110
Sensor Material: Silicone
Length Sensor Cable: 3 m
Diameter Sensor Cable: 5.5 mm
Diameter Sensor Head: 6.5 mm
Temperature Sensor Cable Max.: 160 °C
