Rittal SV9344.020 NH Fuse Switch Disconnector

Name: RITTAL SV9344.020 NH FUSE SWITCH DISCONNECTOR
SKU: 1079517
Availability: LimitedAvailability

rittal-SV9344.020-nh-switch-disconnector-(New)

rittal-SV9344.020-nh-switch-disconnector-(New)-1

rittal-SV9344.020-nh-switch-disconnector-(New)-2

rittal-SV9344.020-nh-switch-disconnector-(New)-3

rittal-SV9344.020-nh-switch-disconnector-(New)-4

rittal-SV9344.020-nh-switch-disconnector-(New)-5

Nouveau

En stock1 unitéPrêt à être expédié

Fuse Switch-Disconnector

RITTAL NH fuse switch-disconnector SV 9344.020 with 3-pole design, 160 A rated current, and NH00 fuse size. Provides safe power distribution with IP20 protection.

Fabricant

RITTAL

SKU

1079517

Catégorie

Fuses & Fuse Holders

Condition

Nouveau

095558 160A 3-Pole 9344.020 Disconnector Distribution Fuse Housing Industrial IP20 NH NH00 Polyamide Power Protection Rittal Size SV Switch Switch-Disconnector

Stock massif

Expédition mondiale

Support Expert

Qualité garantie

RITTAL SV 9344020 NH Fuse Switch-Disconnector

The RITTAL SV 9344.020 NH Fuse Switch-Disconnector is designed for reliable power distribution and protection in industrial electrical systems. Built with robust polyamide housing and compact dimensions, it ensures safe disconnection and effective operation in demanding environments.

Manufacturer: RITTAL

Type: NH Fuse Switch-Disconnector

Model: SV 9344.020

Part No.: 095558

Rated Operating Voltage	400 / 690 V AC
Rated Operating Current Max.	160 A
Frequency	50 / 60 Hz
Fuse Size	NH00
Poles No.	3-Pole
Contact	1 NO + 1 NC
Contact Ratings	250 V AC / 30 V DC, 5 A
Material	Polyamide
Protection Class	IP20
Ambient Temperature	-20 / 55 °C
Dimension	194 x 106 x 87 mm
