Schneider Electric GV2ME16AP Motor Circuit Breaker

Manufacturer: Schneider Electric

Type: Motor Circuit Breaker

Model: GV2ME16AP

Part No.: 960769

Nominal operating voltage (Ue): 690 V

Rated impulse withstand voltage (U_imp): 6 KV

Frequency: 50/60 Hz

Thermal protection adjustment range: 9 … 14 A

Tightening torque: 15 Ib.in

Number of pole/s: 3 poles

Operating Temperature: -20 … +60 °C

Type of protection: Explosion protection EX

Dimensions: 89 x 45 x 78.5 mm
