Siemens 3RK1400-1CG00-0AA2 AS-I Slimline Module
Utilisé
En stock2 unitésPrêt à être expédié
AS-i SlimLine Module SIEMENS AS-i SlimLine S22.5 I/O module with 4 digital inputs and 4 solid-state outputs, designed for industrial control cabinet and automation applications.
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
| Code | G/ 061206E43 |
| design of the product | SlimLine S22.5 - I/O modules for operation in the control cabinet |
| design of the slave type | standard slave |
| I/O configuration | 7 |
| type of voltage supply for sensor supply | using AS-Interface |
| input voltage | 20 ... 30 V |
| number of digital inputs | 4 |
| type of connection technology | 2- and 3-wire technology |
| Input circuit | PNP transistor |
| Inputs switching level High min | 10 V |
| input current at digital input | (for signal <1> minimum: 5 mA), (with signal maximum: 1,5 mA) |
| number of digital outputs | 4 |
| type of switching output | solid state |
| ambient temperature | -25 ... +70 °C |
| width | 45 mm |
| height | 108 mm |
| depth | 86 mm |
| fastening method | 35 mm standard rail mounting or wall mounting using push-in |
| Condition | Used |
| Stock key | CON003 |
| SKU | 1093813 |
| Weight | 0,21 |
