Siemens 3RV2011-4AA15 Circuit Breaker
Utilisé
En stock2 unitésPrêt à être expédié
Disjoncteur robuste Siemens triphasé avec courant de fonctionnement de 16 A, plage de tension 20 / 690 V, et protection IP20. Conçu pour une protection fiable des moteurs et la prévention des surcharges.
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
SIEMENS 3RV2 011-4AA15 CIRCUIT BREAKER
The Siemens 3RV2 011-4AA15 is a robust and efficient circuit breaker designed for reliable motor protection and overload prevention in industrial electrical systems. Built for durability and precision, it ensures optimal performance across a wide voltage range and is suitable for demanding environments.
Manufacturer: Siemens
Type: Circuit Breaker
Model: 3RV2 011-4AA15
Ref No.: G/120920
Operating Power
At AC-3:
At AC-3e:
| Operating Voltage | 20 / 690 V |
| Operating Frequency | 50 / 60 Hz |
| Operational Current | 16 A |
| Surge Voltage Resistance Rated Value | 6 kV |
| Power Loss at AC in Hot Operating State | 9.25 W |
| Power Loss at AC in Hot Operating State Per Pole | 3.1 W |
| Number of Poles for Main Current Circuit | 3 |
| At 230 V Rated Value | 4 kW |
| At 400 V Rated Value | 5 kW |
| At 500 V Rated Value | 5 kW |
| At 690 V Rated Value | 11 kW |
| At 230 V Rated Value | 4 kW |
| At 400 V Rated Value | 5 kW |
| At 500 V Rated Value | 5 kW |
| At 690 V Rated Value | 11 kW |
| Operation Temperature | -20 / 60 °C |
| Protection Class | IP20 |
| Dimensions | 97 x 45 x 97 mm |
