SKF 6310-2Z/VA208 Deep Groove Ball Bearing

Manufacturer: SKF

Type: DEEP GROOVE BALL BEARING

Model: 6310-2Z/VA208

SKF ball bearings for high as well as low temperatures correspond in design to the appropriate standard single row deep groove ball bearings. They have no filling slots and are able to accomodate moderate axial loads in addition to radial loads.

A feature of these bearings include large radial internal clearance which is four times the C5 clearance preventing them from seizing even when they are rapidly cooled. All surfaces of the bearing are manganese phosphated, providing protection against corrosion and improving running properties.

Outside Diameter: 110 mm

Inside Diameter: 50 mm

Width: 27 mm

Basic Static Load Ratings: 38 kN

Basic Dynamic Load Ratings: 65 kN

Limiting Speed: 50 r/min

Limiting Temperature: 350 °C
