Sprecher+Schuh CT 3-12 0.24-0.38A Thermal Overload Relay

Name: SPRECHER+SCHUH CT 3-12 0.24-0.38A THERMAL OVERLOAD RELAY
SKU: 1091692
Price: 39.99 USD
Availability: InStock

sprecher-schuh-CT-3-12-0.24-0.38A-thermal-overload-relay-(Used)

sprecher-schuh-CT-3-12-0.24-0.38A-thermal-overload-relay-(Used)-1

sprecher-schuh-CT-3-12-0.24-0.38A-thermal-overload-relay-(Used)-2

sprecher-schuh-CT-3-12-0.24-0.38A-thermal-overload-relay-(Used)-3

Utilisé

En stock1 unitéPrêt à être expédié

39,99$

Relais thermique de surcharge réglable avec contacts NO et NC, conçu pour une protection fiable des moteurs dans les applications de contrôle industriel.

Fabricant

SPRECHER+SCHUH

SKU

1091692

Catégorie

Contactors & Accessories

Condition

Utilisé

accessory Adjustable Control Industrial motor Overload Panel Protection Relay Sprecher+Schuh Thermal

Stock massif

Expédition mondiale

Support Expert

Qualité garantie

SPRECHER+SCHUH CT3-12 Thermal Overload Relay

The SPRECHER+SCHUH CT3-12 thermal overload relay is designed to protect electric motors against overload conditions. It provides accurate current adjustment and reliable tripping performance, making it suitable for industrial motor control and protection applications.

Manufacturer: SPRECHER+SCHUH

Type: Thermal Overload Relay

Model: CT3-12 0.24-0.38A

Rated Operational Voltage (Max.)	600 V AC
Rated Thermal Current	25 / 2 A
Frequency	50 / 60 Hz
Adjustable Current Range	0.24 / 0.38 A
Contact Configuration	1 Normally Open (NO) + 1 Normally Closed (NC)
Contact Current	10 / 6 A
Ambient Temperature	-25 / 50 °C
Dimensions	65 x 45 x 52 mm
