Synrad 48-1SAM Carbon Dioxide Laser

Manufacturer: SYNRAD

Type: CARBON DIOXIDE LASER

Series: 48

Version Model: M

Model: 48-1SAM

Serial No.: 0481002130003

Used For: Identify and develop the best CO2 laser solution for a given application

Power Supply:

  Voltage: 30 V DC

  Max. Current: 7.0 A

Cooling Options: Air

Voltage:

 Off State: 0 … 0.5 VDC, 0.0 V Nominal

 On State: 3.5 … 10 VDC, 5.0 V Nominal

Max. Current Load: 6 mA

Dimensions ( Length x Width x Height ): 42.9 cm x 7.1 cm x 10.7 cm

Beam Diameter: 3.5 mm

Min. thread engagement: 5 mm

Max. thread engagement: 7.6 mm

Max. Heat Load: 30 Watt

Max. Torque: 0.41 Nm

Output Power:

  8W @ 9.3µm

  10W @ 10.6µm

Tickle Frequency: 5 kHz

Frequency: 5 … 20 kHz

Humidity:  0% … 95%

Safety Options: OEM

Temperature: 15 … 40 °C

Weight: 4.40 kg
