Telemecanique VZ12 Additional Neutral Block
Bloc neutre supplémentaire Le bloc neutre supplémentaire Telemecanique VZ12 assure une distribution efficace de la puissance avec une tension nominale de 690V AC, un courant de 80A et une tension d'impulsion nominale de 6kV. Il est doté d’une protection IP20 et d’un design compact pour usage industriel.
Telemecanique VZ12 Additional Neutral Block
The **Telemecanique VZ12 Additional Neutral Block** is a high-performance electrical component designed for use in various industrial applications. It features a **690 V AC operating voltage** and is built to handle **80 A current** with a **6 kV rated impulse voltage**. This block ensures safe and efficient power distribution with its IP20 protection and wide operating temperature range.
Manufacturer: TELEMECANIQUE
Type: Additional Neutral Block
Model: VZ12
Part No.: 055191
Technical Data:
- Rated Operating Voltage: 690 V AC
- Rated Current: 80 A
- Frequency: 50 / 60 Hz
- Rated Impulse Voltage (Uimp): 6 kV
- Contact: 1 Normally Open (NO)
- Number of Poles: 1 Pole
- Protection Class: IP20
- Ambient Temperature: -20 / 50 °C
- Dimensions: 83 x 20 x 46 mm
