VEGA B82.AXC3SDGTEZXKIMXX Pressure transmitter
Nouveau
En stock2 unitésPrêt à être expédié
399,99$
VEGA VEGABAR 82 Pressure Transmitter The VEGA VEGABAR 82 is a high-accuracy pressure transmitter with ceramic measuring cell designed for demanding industrial process applications. Featuring 4…20 mA two-wire electronics, 0.05% accuracy, stainless steel wetted parts, and IP66/IP67 protection for reliable long-term operation.
Series:
VEGABAR 82
Operating Voltage:
9.6 … 35 V DC
Output Signal:
4 … 20 mA
Measuring Accuracy:
0.05 %
Pressure Range:
-1 … 0.0 Bar
Working Pressure:
-1 To +23 Bar
Protection:
IP66/IP67 TYPE 4X
0.2AccuracyANDApplicationsAtexDeltabardemandingdifferentialFieldbusforFoundationHartIndustrialInstrumentationIP66PAPresPressureProcessProfibusProtectionSensorsTransmitter
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
| Series | VEGABAR 82 |
| Part No. | B82.AXC3SDGTEZXKIMXX |
| Ref NO | 4500033203/ 3287272/1 |
| SN | 69926166 |
| Code | BAR 82 |
| Operating voltage | 9.6 … 35 V DC |
| Electronics versions ,two-wire electronics with | 4 … 20 mA |
| Process fitting / Material | Thread G1/2, front-flush /316L |
| Measuring range | -1 ... 0.0bar (-100 ... 0kPa) |
| Max Working pressure | -1 to +23bar |
| Process temperature | -40 ... 150 °C |
| Materials, wetted parts | Al203,EPDM,316L |
| Accuracy | 0.05 % |
| Process fitting | M20x1,5 |
| Threaded connection | G¼ |
| Flange connection | DN15 |
| Ambient temperature | -40 ... 80 °C |
| Protection | IP66/IP67 TYPE 4X |
| Stock Key | CON-003 |
| Condition | New |
| SKU | 1099054 |
| Weight | 0,56 |
