NSK W3205M-19Z-C5Z-96S6-3001 Ball Screw
Flange Nut Ball Screw (Model: W3205M-19Z-C5Z-96S6-3001)
Manufacturer: NSK
Type: Flange Nut Ball Screw
Model: W3205M-19Z-C5Z-96S6-3001
The NSK Flange Nut Ball Screw (Model: W3205M-19Z-C5Z-96S6-3001) is designed for high-performance applications with precision features such as zero clearance preload and accurate ball screw specifications. Ideal for mechanical systems requiring precise motion control and durability.
- Manufacturer: NSK
- Type: Flange Nut Ball Screw
- Model: W3205M-19Z-C5Z-96S6-3001
- Size: 32 x 5 R
- Nominal Diameter (dN): 32 mm
- Lead (P): 5 mm
- Number of Starts: 1
- Direction of Lead: Right-Hand Thread
- Threaded Length: 550 mm
- Total Screw Length: 750 mm
- Accuracy Grade: C5
- Clearance/Preload Code: Z, Preloaded (Zero Clearance)
- Design Sequence Number: 19
- Ball Screw Specifications / Appearance: Z, Single Nut, Offset Type Preload
