Sick AFM60A-S4NB018X12 Absolute Encoder
669,99$
ABSOLUTE ENCODER SICK AFM60A-S4NB018X12 PROFINET इंटरफ़ेस के साथ पूर्णांक एन्कोडर, 18 × 12 बिट रिज़ॉल्यूशन, 262,144 स्टेप्स, 4,096 रेवोल्यूशन्स, 10“30 V DC सप्लाई, IP65/IP67 सुरक्षा, और सॉलिड शाफ्ट फ्लैन्ज़ डिज़ाइन।
SICK AFM60A-S4NB018X12 Absolute Encoder
The SICK AFM60A-S4NB018X12 is a high-precision absolute encoder engineered for demanding industrial automation and motion control applications. Offering PROFINET connectivity, high resolution, and robust construction with stainless steel and aluminum materials, it ensures reliable and accurate feedback even under challenging conditions.
Manufacturer: SICK
Type: Absolute Encoder
Model: AFM60A-S4NB018X12
| Supply Voltage | 10 / 30 V |
| Power Consumption | 3 W (without load) |
| Max. Resolution | 18 bit x 12 bit (262,144 x 4,096) |
| Data Transmission Rate | 10 Mbit/s, 100 Mbit/s |
| Transmission Medium | CAT-5e cable |
| Initialization Time | 6 s |
| Cycle Time | 1 ms |
| Connection Type | Male connector (M12, 4-pin, axial), Female connector (M12, 4-pin, axial, 2x) |
| Mechanical Design | Solid shaft, face mount flange |
| Shaft Diameter | 10 mm |
| Shaft Length | 19 mm |
| Shaft Material | Stainless steel |
| Flange Material | Aluminum |
| Housing Material | Aluminum |
| Operating Torque | 0.3 N cm (20 °C) |
| Operating Speed | 9,000 min»¹ |
| Enclosure Rating | IP65 (shaft side), IP67 (housing side) |
| Operating Temperature Range | “40 °C / +85 °C |
