Eaton PKZM0-4 Motor Protective Circuit Breaker
Used
In stock1 unitReady to ship
Motor Protective Circuit Breaker The EATON PKZM0-4 is a 3-pole motor protective circuit breaker rated at 4 A and 690 V, designed for reliable industrial motor protection.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Rated Operational Voltage (Ue) | 690 V |
| Rated Operational Current (In) | 4 A |
| Overload Release Current Setting Range | 2.5 … 4 A |
| Frequency | 50 … 60 Hz |
| Rated Impulse Voltage (Uimp) | 6 kV |
| Rated Operational Power AC-3 | 380/400 V: 1.5 kW |
| Service Switching Capacity (Ics) | 400/440/500 V AC: 150 kA / 690 V AC: 3 kA |
| Breaking Switching Capacity (Icu) | 400/440/500 V AC: 150 kA / 690 V AC: 3 kA |
| Power Loss | 5.33 W |
| No. of Poles | 3-Pole |
| Protection Class | IP20 |
| Connection | Screw Terminals |
| Ambient Temperature | -25 … 55 °C |
| Dimensions | 76 x 45 x 93 mm |
| Stock Key | CON003 |
| Condition | Used |
| SKU | 1103872 |
| Weight | 0,3 |
