Eaton PLSM-C16/3-MW Miniature Circuit Breaker
New
In stock1 unitReady to ship
Miniature Circuit Breaker Three-pole EATON miniature circuit breaker with C tripping characteristic, 16 A rated current, and 10 kA breaking capacity, designed for industrial electrical circuit protection.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Number of poles | 3 |
| Tripping characteristic | C |
| Rated current | 16 A |
| Rated voltage | 400 V DC |
| Rated insulation voltage | 440V |
| Rated impulse withstand voltage | 4 kV |
| Rated short-circuit breaking capacity Icn | 10 kA |
| Rated short-circuit breaking capacity Icu | 0 kA |
| Product range | PLSM |
| Frequency | 50 – 60 Hz |
| Terminals top and bottom | Twin-purpose terminals |
| Mounting width per pole | 17,5 mm |
| Enclosure height | 80 mm |
| Degree of Protection | IP20, IP40 |
| Operating ambient temperature | -40 to 75 °C |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093891 |
| Weight | 0,32 |
