Schneider XCKP2118G11 Limit Switch

Manufacturer: Schneider
Type: Limit Switch
Model: XCKP2118G11
Part No: 030137

Insulation Voltage: 500 V
Impulse Withstand Voltage: 6 kV
Max. Conduit Torque: 8 Nm
Contact Configuration: 1 Normally Open, 1 Normally Close
Contact Voltage: 240 V AC
Contact Current: 3 A
Thermal Current: 10 A
Head type: Rotary head

Body material: Plastic

Head material: Zamak
Movement of operating head: Rotary
Type of operator: Spring Return Roller Lever Thermoplastic
Number of poles: 2
Operating Temperature: -25 … 70 °C
Degree of protection: IP66/ IP67
Dimensions: 31 X 65 X 30 mm
