INA NUKRE62 Stud Type Track Roller
Novo
Em estoque2 unidadesPronto para envio
Rolamento de trilho tipo pino de alto desempenho INA / Schaeffler NUKRE62 com furo de 24 mm, diâmetro externo de 62 mm e largura de 80 mm. Projetado para alta capacidade de carga radial e rotação suave em sistemas de movimento industriais.
bearingCamComponentDutyFollowerHeavyInaIndustrialMechanicalMotionNUKRE62RollerSchaefflerStudSystemtrackType
Grande Estoque
Envio Global
Suporte Especializado
Qualidade Garantida
INA / Schaeffler NUKRE62 Stud Type Track Roller
The INA / Schaeffler NUKRE62 is a precision-engineered stud type track roller designed to handle high radial loads and deliver reliable performance in demanding motion systems.
Manufacturer: INA / Schaeffler
Type: Stud Type Track Roller
Model: NUKRE62
Code: 02/Z10
| Bore Diameter (d) | 24 mm |
| Outer Diameter (D) | 62 mm |
| Bearing Width (B) | 80 mm |
| Basic Dynamic Load Rating, Radial | 41,000 N |
| Basic Static Load Rating, Radial | 54,000 N |
| Fatigue Load Limit, Radial | 7,400 N |
| Speed on Permanent Grease Lubrication | 2,600 1/min |
| Permissible Static Load, Radial | 46,000 N |
| Permissible Dynamic Load Outer Ring, Radial | 23,300 N |
