LDK UCFA 209 Adjustable Flange Unit
The LDK UCFA 209 Adjustable Flange Unit is a versatile and precision-engineered solution for industrial applications. Featuring the FA 209 housing and UC 209 bearing, this unit ensures reliable performance, stability, and ease of adjustment for various operational needs.
Manufacturer: LDK
Type: ADJUSTABLE FLANGE UNIT
Model: UCFA 209
The LDK UCFA 209 Adjustable Flange Unit is designed for applications that require flexibility, precision, and reliable alignment, making it ideal for industrial machinery and automation systems.
| Bearing No. | UC 209 |
| Housing No. | FA 209 |
| Bore Diameter (d) | 45 mm |
| Overall Length | 180 mm |
| Overall Height | 110 mm |
| Width of Inner Ring | 49.2 mm |
| Distance Between Attachment Bolts | 148 mm |
| Overall Unit Width | 52.2 mm |
| Diameter of Attachment Bolt Hole | 15 mm |
| Bolt Size | M14 |
| Locking Device | Set-Screw |
