SKF Fytb 35FM Oval Flanged Ball Bearing Unit
44,44$
Unidade de rolamento de esferas flangeada oval SKF FYTB 35 FM com inserto de rolamento YET 207, unidade flangeada oval fabricada em ferro fundido, com furo de 35 mm, alta capacidade de carga e design de dupla vedação para aplicações industriais confiáveis.
SKF FYTB 35 FM Oval Flanged Ball Bearing Unit
The SKF FYTB 35 FM is a high-quality oval flanged ball bearing unit designed for easy installation and reliable performance in demanding industrial applications. Featuring a YET 207 bearing insert, this unit provides excellent load-carrying capacity, long service life, and smooth operation. The robust cast iron housing ensures durability, while the double-sealed bearing design protects against contaminants and moisture.
Manufacturer: SKF
Type: Oval Flanged Ball Bearing Unit
Model: FYTB 35 FM
Bearing No.: YET 207
| Bore Diameter (d) | 35 mm |
| Width of Housing (A) | 34.5 mm |
| Width of Inner Ring (B) | 25.4 mm |
| Overall Bearing Width (B1) | 38.9 mm |
| Centre Distance Between Bolt Holes (J) | 130 mm |
| Overall Length (L) | 96 mm |
| Overall Height (H) | 156 mm |
| Diameter of Attachment Bolt Hole (N) | 14 mm |
| Overall Width (T) | 50.4 mm |
| Basic Dynamic Load Rating (C) | 25.5 kN |
| Basic Static Load Rating (C0) | 15.3 kN |
| Fatigue Load Limit (Pu) | 0.655 kN |
| Limiting Speed | 5300 r/min |
| Housing Type | Flanged |
| Flanged Housing Type | Oval |
| No. of Bolt Holes | 2 |
| Material, Housing | Cast Iron |
| Material, Bearing | Bearing Steel |
| Sealing, Bearing | Seal on both sides |
| Sealing, Unit | Optional end cover |
