Hiwin WEH21CA Linear Guideway Block
Yeni
Stokta12 ünitelerSevkiyata hazır
163,13$
LINEER KILİT BLOĞU Hiwin WEH21CA kare tip linear blok, 21 mm boyutunda, üst montaj tasarımı ve dört sıralı geniş ray yapısına sahip, ağır yük taşıma ve hassas hareket sistemleri için tasarlanmıştır.
21BlockGuideGuidewayHeavyHiwinLinearLoadmmMotionMountingPrecisionrailSeriesSquareSystemTopTypeWEWEH21CA
Geniş Stok
Küresel Nakliye
Uzman Destek
Kalite Garantili
HIWIN WEH21CA LINEAR GUIDEWAY BLOCK
The Hiwin WEH21CA linear guideway block belongs to the WE Series, designed with a four-row wide rail structure to support high loads and maintain precision alignment. This square-type block (Type H) offers mounting from the top (Type A) and is engineered for demanding motion applications where both dynamic and static load capacity are critical.
Manufacturer: Hiwin
Type: Linear Guideway Block
Model: WEH21CA
MRN: WEH21 A08JE401
| Size | 21 mm |
| Total Height (H) | 21 mm |
| Block Width (W) | 54 mm |
| Block Length (L) | 59 mm |
| Block Height | 18 mm |
| Distance Between Holes | 31 mm, 19 mm |
| Basic Load Rating - Dynamic (Cr) | 7.2 kN |
| Basic Load Rating - Static (C‚r) | 13.7 kN |
| Series | WE Series; Four-Row Wide Rail Linear Guideway |
| Block Type | H; Square Type |
| Load Type | C; Heavy Load |
| Block Mounting | A; Mounting from Top |
