INA Natv 20 PP Yoke Type Track Roller

Manufacturer: INA Schaeffler
Type: Yoke Type Track Roller
Model: NATV20-PP

Dimensions
Bore Diameter d: 20 mm
Outer diameter D: 47 mm
Width of Bearing B: 25 mm
Basic dynamic load rating,radial: 20,200 N
Basic static load rating,radial: 42,500 N
Fatigue load limit, radial: 6,000 N
Speed on permanent grease lubrication: 1,300 1/min
Permissible static load, radial: 42,500 N
Permissible dynamic load outer ring, radial: 42,500 N
Sealing: Three-stage sealing by plastic axial plain washer on both sides
