THK CF10UU CAM Follower
Yeni
Stokta2 ünitelerSevkiyata hazır
Altıgen lokmalı THK CF10UU kam takipçi, sızdırmaz tasarım ve hassas endüstriyel hareket uygulamaları için yüksek yük kapasitesi.
Geniş Stok
Küresel Nakliye
Uzman Destek
Kalite Garantili
THK CF10UU Cam Follower
The THK CF10UU is a precision cam follower featuring a hexagon socket design and integrated sealing. It is engineered for smooth rolling motion, high load capacity, and reliable performance in industrial mechanical systems.
Manufacturer: THK
Type: Cam Follower with Hexagon Socket
Model: CF10UU
| Outside Diameter (D) | 22 mm |
| Attachment Diameter (d) | 10 mm |
| Total Length (B1) | 36 mm |
| Outer Ring Width (C) | 12 mm |
| Thread Stud (G) | M10 × 1.25 |
| Dynamic Load Rating (C) | 5.33 kN |
| Static Load Rating (C0) | 6.78 kN |
| Track Load Capacity | 4.7 kN |
| Maximum Permissible Load | 5.81 kN |
| Rotational Speed Limit | 17,000 rpm |
| Sealing | UU, With Seal |
| No. of Items / Set | 2 |
