FAG 3206-BD-2HRS-TVH Angular Contact Ball Bearing
جديد
متوفر2 وحداتجاهز للشحن
محمل كرات اتصال زاوي مزدوج الصف FAG 3206-BD-2HRS-TVH محمل كرات اتصال زاوي مزدوج الصف مع فتحة 30 مم، مختوم من الجانبين، وذو قدرة تحميل عالية للتطبيقات الصناعية.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
FAG 3206-BD-2HRS-TVH Double Row Angular Contact Ball Bearing
The FAG 3206-BD-2HRS-TVH is a double row angular contact ball bearing designed to accommodate combined radial and axial loads while providing high rigidity and reliable operation in industrial applications.
Manufacturer: FAG / Schaeffler
Type: Double Row Angular Contact Ball Bearing
Model: 3206-BD-2HRS-TVH
| Bore Diameter (d) | 30 mm |
| Outer Diameter (D) | 62 mm |
| Width (B) | 23.8 mm |
| Contact Angle | 30° |
| Dynamic Load Rating (Cr) | 31,000 N |
| Static Load Rating (C0r) | 22,200 N |
| Fatigue Load Limit (Cur) | 1,540 N |
| Limiting Speed | 9,000 1/min |
| Seal | 2HRS, contact seal on both sides |
| Cage | TVH, solid cage made of glass-fiber reinforced polyamide PA66 |
| Design Variant | B, bearing without filling slot |
| Internal Design | D, changed internal design |
| Operating Temperature Range | -20 to +100 °C |
