Hawe MVE4E Pressure-Limiting Valve
مستعمل
متوفر2 وحداتجاهز للشحن
Pressure-Limiting Valve
HAWE MVE 4 E hydraulic pressure-limiting valve with cone-seated design, size 4, suitable for oil systems. Rated for up to 700 bar operating pressure and 8 lpm flow rate, with ambient temperature range from -40 to +80 °C.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
HAWE MVE 4 E Pressure-Limiting Valve
The HAWE MVE 4 E is a high-pressure hydraulic pressure-limiting valve designed for precise pressure control in demanding hydraulic systems. Featuring a cone-seated valve design, it ensures reliable sealing performance and stable operation under extreme pressure conditions.
Manufacturer: HAWE
Type: Pressure-Limiting Valve
Model: MVE 4 E
Code: G04 205
Series: MVE
| Size | 4 |
| Fluid | Oil |
| Design | Cone-Seated Valve |
| Ambient Temperature | Approx. -40 to +80 °C |
| Maximum Operating Pressure (pmax) | 700 bar |
| Maximum Flow Rate (Qmax) | 8 lpm |
