Hohner 30 3000 Incremental Encoder

Name: HOHNER 30 3000 INCREMENTAL ENCODER
SKU: 1086863
Price: 144.44 USD
Availability: InStock

hohner-30-3000-incrementa-encoder-used-1

hohner-30-3000-incrementa-encoder-used-2

مستعمل

متوفر2 وحداتجاهز للشحن

144,44$

INCREMENTAL ENCODER

Hohner 303000 incremental encoder from the 30 series with 12 mm shaft, 90 mm diameter, 5 PPR output, NPN 11“30 V DC, IP65 protection, and long bearing lifetime.

الشركة المصنّعة

HOHNER

SKU

1086863

الفئة

Rotary Encoders

الحالة

مستعمل

12 2 30 303000 5 Control DO Encoder Hohner Incremental Industrial IP65 mm Motion NPN Output PPR Series shaft stainless Steel

مخزون ضخم

شحن عالمي

دعم من خبراء

جودة مضمونة

Hohner 303000 Incremental Encoder

The Hohner 303000 is a precision incremental encoder from the 30 series, designed for reliable performance in motion control and industrial automation. Built with durable materials, IP65 protection, and long bearing life, it ensures accurate signal output and extended service life.

Manufacturer: Hohner

Type: Incremental Encoder

Model: 303000

Series: 30

Code: 2 Do

Shaft	12 mm
External Diameter	90 mm
Protection	IP65
Output Signal	A
Pulses	5 PPR
Temperature Range	-20 to 80 °C
Connection	Axial cable
Output Circuits	NPN 5/24 V (11 to 30 V DC)
Current	40 mA
Length of Cable	Up to 50 m
No. of Revolutions Permitted	6000 rpm
Materials	Cover: Aluminium, Housing: Aluminium, Shaft: Stainless Steel
Bearings Lifetime	1 Ã— 10^10 revolutions
