Schneider Electric ATV340U07N4 Variable Speed Drive
جديد
متوفر2 وحداتجاهز للشحن
Variable Speed Drive
Schneider Electric Altivar Machine ATV340 variable speed drive rated at 0.75 kW, designed for precise motor control, flexible I/O configuration, and industrial automation applications.(VSD)ACAltivarATV340AutomationDriveElectricFrequencyIndustrialInverterMachinemotorSchneiderSpeedVariable
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
SCHNEIDER ELECTRIC ATV340U07N4 Variable Speed Drive
The Schneider Electric ATV340U07N4 variable speed drive from the Altivar Machine ATV340 range is designed for advanced motor control in industrial automation and machine applications. It delivers precise speed regulation, flexible I/O configuration, and reliable performance for demanding environments.
Manufacturer: SCHNEIDER ELECTRIC
Type: Variable Speed Drive
Model: ATV340U07N4
Range: Altivar Machine ATV340
| Input Supply Voltage | 3-Phase 380 / 480 V AC |
| Input Rated Current | 3.4 A |
| Input Frequency | 50 / 60 Hz |
| Output Rated Voltage | 3-Phase 0 / 500 V AC |
| Output Rated Current | 2.2 A |
| Output Frequency | 0 / 599 Hz |
| Motor Power | 0.75 kW / 1 HP |
| Discrete Input Number | 5 |
| Discrete Output Number | 2 |
| Analogue Input Number | 2 |
| Analogue Output Number | 1 |
| Relay Output Number | 2 |
| Number of Preset Speeds | 16 |
| Protection Class | IP20 |
| Ambient Temperature | -10 / 50 °C |
| Dimensions | 270 x 85 x 232 mm |
