IVO Baumer GM401.E15 427928 27.03 Absolute Encoder
Usado
En stock2 unidadesListo para enviar
199,99$
ENCÓDER ABSOLUTO MULTIVUELTA IVO Baumer GM401.E15 es un codificador absoluto multivuelta con salida SSI binaria, resolución 4096 x 4069 y carcasa de aluminio robusta. Diseñado para control de movimiento preciso en sistemas de automatización industrial.
586AbsoluteAluminiumBaumerBinaryControlEncoderFlangeGM401.E15HousingIndustrialIVOmmMotionMultiturnOutputSensorshaftSSI
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
IVO BAUMER GM401.E15 ABSOLUTE ENCODER
The IVO Baumer GM401.E15 is a high-precision multiturn absolute encoder engineered for industrial-grade applications. Offering reliable performance and robust construction, this encoder is ideal for motion control systems demanding accuracy and stability.
Manufacturer: IVO Baumer
Type: Absolute Encoder
Model: GM401.E15
Part No.: 427928 27.03
Material
| Voltage Supply | 10 / 30 VDC |
| Encoder Type | Multiturn |
| Resolution | 4096 x 4069 |
| Output Code | Binary Code SSI |
| Size (Flange) | 58 mm |
| Shaft Type | 6 mm Solid Shaft |
| Connection Type | Connector M23, 12-pin, Radial |
| Operating Temperature | -25...+85 °C |
| Housing | Aluminium |
| Flange | Aluminium |
