THK SSR15XW Linear Guideway Block
65,00$
Bloque de guía lineal THK SSR 15XW1SSM tipo cuadrado diseñado para sistemas de movimiento lineal de precisión, ofreciendo alta rigidez, movimiento suave y capacidad de carga confiable para aplicaciones CNC y automatización industrial.
THK SSR 15XW1SSM Linear Guideway Block
The THK SSR 15XW1SSM Linear Guideway Block is a precision-engineered square-type linear motion block designed for smooth, accurate, and stable linear movement in industrial automation and machine systems. Manufactured by THK, this linear guide block provides high rigidity, reliable load capacity, and excellent motion accuracy for demanding motion control applications.
Manufacturer: THK
Type: Linear Guideway Block
Model: SSR 15XW1SSM
Dimensions
| Size | 15 mm |
| Block Type | Square Type |
| Basic Dynamic Load Rating (C) | 14.7 kN |
| Basic Static Load Rating (C0) | 16.5 kN |
| Mounting Hole Pitch B | 26 mm (Width Direction) |
| Mounting Screw Size | M4 x 7 mm Depth |
| L1 | 39.9 mm |
| T | 6.5 mm |
| K | 19.5 mm |
| N | 4.5 mm |
| E | 5.5 mm |
| H3 | 4.5 mm |
| Total Height (M) | 24 mm |
| Block Width (W) | 34 mm |
| Block Length (L) | 56.9 mm |
| Recommendation | Ideal for CNC machines, automation equipment, and precision linear motion systems where smooth movement and high load capacity are essential. |
