Brueninghaus Hydromatik A10VSO 45 DFR1/31R-PPA12N00 Axial Piston Variable Pump

Name: BRUENINGHAUS HYDROMATIK A10VSO 45 DFR1/31R-PPA12N00 AXIAL PISTON VARIABLE PUMP
SKU: 988637
Price: 2475.00 USD
Availability: InStock

brueninghaus-hydromatik-a10vso-45-dfr1_31r-ppa12n00-axial-piston-variable-pump-1

brueninghaus-hydromatik-a10vso-45-dfr1_31r-ppa12n00-axial-piston-variable-pump-2

brueninghaus-hydromatik-a10vso-45-dfr1_31r-ppa12n00-axial-piston-variable-pump-3

Utilisé

En stock1 unitéPrêt à être expédié

2 475,00$

SKU

988637

Catégorie

Piston Pumps

Condition

Utilisé

45 A10VSO Axial Piston pump Pumps Series Size Variable

Stock massif

Expédition mondiale

Support Expert

Qualité garantie

Manufacturer: Brueninghaus Hydromatik / Rexroth

Type: Axial Piston Variable Pump

Model: A10VSO45DFR1/31R-PPA12N00

Size: 45

Displacement: 45 cm³Maximum Speed: 2600 rpm

Flow Rate at 1500 rpm: 68 l/m

Power at 280 bar, 1500 rpm: 32 KW

Torque at 280 bar: 200 N.M

Nominal pressure: 280 bar

Shaft Diameter: 25 mm

Control Device: X-T plugged, with flushing function

Direction of Rotation: Clockwise

Mounting Flange: ISO 3019-2 (2 holes)

Viscosity Range: 16 …. 36 mm²/s

Weight: 22.5 Kg
