Hydraulics & Pneumatics Pneumatic Actuators

Flowserve SID085D Pneumatic Actuator

Name: FLOWSERVE SID085D PNEUMATIC ACTUATOR
SKU: 1083897
Availability: LimitedAvailability

AUTOMAX-SID085D-pneumatic-actuator(used)

AUTOMAX-SID085D-pneumatic-actuator(used)-1

AUTOMAX-SID085D-pneumatic-actuator(used)-2

AUTOMAX-SID085D-pneumatic-actuator(used)-3

AUTOMAX-SID085D-pneumatic-actuator(used)-4

AUTOMAX-SID085D-pneumatic-actuator(used)-5

Utilisé

En stock1 unitéPrêt à être expédié

Pneumatic Actuator

The Flowserve Automax MECAIR SID085D is a double acting pneumatic actuator with an aluminum body, IP66 protection, and ISO 5211 mounting for reliable industrial valve control.

Fabricant

FLOWSERVE

SKU

1083897

Catégorie

Pneumatic Actuators

Condition

Utilisé

5211 Acting Actuator Aluminum Automation Automax Control Double Flowserve Industrial IP66 ISO Mecair Pneumatic S100 SID085D SuperNova Valve

Stock massif

Expédition mondiale

Support Expert

Qualité garantie

Flowserve Automax MECAIR SID085D Pneumatic Actuator

The Flowserve Automax MECAIR SID085D Pneumatic Actuator is engineered for precise valve control and long service life. Built with a durable aluminum body, it delivers reliable double acting performance under demanding industrial conditions.

Manufacturer: Flowserve / Automax MECAIR

Type: Pneumatic Actuator

Model: SID085D

ID No.: S085-265156

Series: SuperNova S100

Certification Code	CESI GR-91/016273-5
Size	085
Actuation Type	Pneumatic “ Double Acting
Operating Pressure	Max 10 bar
Mounting Standard	IEC 144 / ISO 5211 / NAMUR / VDE 3845
Switchbox Rating	IP66
Material	Aluminum Body
Operating Temperature	-20 °C to +80 °C
Air Ports	1/8 inch NPT
Attached With	AUTOMAX ME 4668 Mounting Bracket Assembly
