Pepperl+Fuchs KFA6-SR2-EX2.W Switch Amplifier
39,99$
Amplificateur à commutation L'amplificateur à commutation Pepperl+Fuchs KFA6-SR2-EX2.W assure une isolation sûre et une transmission fiable des signaux entre les systèmes de terrain et de contrôle. Conçu pour l'automatisation industrielle, il fonctionne sous 207“253 VAC et garantit une conversion d'entrée numérique stable avec des dimensions compactes de 20 x 119 x 115 mm.
Pepperl+Fuchs KFA6-SR2-EX2.W Switch Amplifier
The Pepperl+Fuchs KFA6-SR2-EX2.W is a high-quality switch amplifier designed for safe signal transmission between field devices and control systems. It ensures reliable isolation and conversion of digital input signals in hazardous and industrial environments, providing dependable performance with minimal power loss.
Manufacturer: Pepperl+Fuchs
Type: Switch Amplifier
Model: KFA6-SR2-EX2.W
Part No.: 37370S
Input
Output
Environmental Data
| Signal Type | Digital Input |
| Supply Voltage | 207 / 253 VAC |
| Frequency | 45 / 65 Hz |
| Supply Power Loss | 1.2 W |
| Power Consumption | ‰¤ 1.3 W |
| Connection | terminals 14, 15 |
| Connection Side | Field side |
| Connection | terminals 1+, 2+, 3-; 4+, 5+, 6- |
| Open Circuit Voltage / Short-Circuit Current | approx. 8 VDC / approx. 8 mA |
| Switching Point / Switching Hysteresis | 1.2 / 2.1 mA / approx. 0.2 mA |
| Connection Side | Control side |
| Connection | Output I: terminals 7, 8, 9; Output II: terminals 10, 11, 12 |
| Energized / De-energized Delay | approx. 20 ms / approx. 20 ms |
| Ambient Temperature | -20 / 60 °C |
| Dimensions | 20 x 119 x 115 mm |
