LDK Ucfa 209 Adjustable Flange Unit
समायोज्य फ्लैन्ज यूनिट LDK UCFA 209 समायोज्य फ्लैन्ज यूनिट सटीकता और बहुमुखी प्रतिभा के लिए डिज़ाइन की गई है। FA 209 हाउसिंग और UC 209 बियरिंग के साथ, यह औद्योगिक अनुप्रयोगों के लिए स्थिरता और विश्वसनीय संरेखण प्रदान करती है।
LDK UCFA 209 Adjustable Flange Unit
The LDK UCFA 209 Adjustable Flange Unit is a versatile and precision-engineered solution for industrial applications. Featuring the FA 209 housing and UC 209 bearing, this unit ensures reliable performance, stability, and ease of adjustment for various operational needs.
Manufacturer: LDK
Type: ADJUSTABLE FLANGE UNIT
Model: UCFA 209
The LDK UCFA 209 Adjustable Flange Unit is designed for applications that require flexibility, precision, and reliable alignment, making it ideal for industrial machinery and automation systems.
| Bearing No. | UC 209 |
| Housing No. | FA 209 |
| Bore Diameter (d) | 45 mm |
| Overall Length | 180 mm |
| Overall Height | 110 mm |
| Width of Inner Ring | 49.2 mm |
| Distance Between Attachment Bolts | 148 mm |
| Overall Unit Width | 52.2 mm |
| Diameter of Attachment Bolt Hole | 15 mm |
| Bolt Size | M14 |
| Locking Device | Set-Screw |
