Hubner Berlin POG 9 D 500 Incremental Encoder
Kullanılmış
Stokta23 ünitelerSevkiyata hazır
399,99$
İNCREMENTAL ENCODER Hubner Berlin POG9D500, HTL çıkışlı, 11 mm sağlam şaftlı ve IP56 korumalı 500 ppr sağlam bir optik inkremental enkoderdir. 12000 rpm'ye kadar yüksek hızlı endüstriyel uygulamalar için uygundur.
500BerlinBoxEncoderHTLHubnerIncrementalIndustrialIP56OpticalOutputPOG9D500PPRRatedshaftSolidterminal
Geniş Stok
Küresel Nakliye
Uzman Destek
Kalite Garantili
HUBNER BERLIN POG9D500 INCREMENTAL ENCODER
The POG9D500 from Hubner Berlin is a high-precision incremental encoder built for demanding industrial environments. Featuring a robust aluminum housing, stainless steel shaft, and HTL output, this encoder ensures accurate speed and position feedback under extreme conditions.
Manufacturer: Hubner Berlin
Type: Incremental Encoder
Model: POG9D500
Serial No.: 1342625
| Power Supply | 9 / 30 V DC |
| Current Consumption | ‰¤ 100 mA |
| Operating Principle | Incremental |
| Shaft Type | Solid Shaft |
| Flange | EURO Flange B10 |
| Sensing Method | Optical |
| Output Stage | HTL |
| Output Frequency | ‰¤ 120 kHz |
| Resolution | 500 ppr |
| Operating Speed | ‰¤ 12000 rpm |
| Shaft Diameter | 11 mm |
| Flange Size | ø115 mm |
| Protection Degree | IP56 |
| Material | Housing: Aluminum Die-Cast, Shaft: Stainless Steel |
| Connection | Terminal Box |
| Operating Temperature | -30 / +100 °C |
