Koyo UCT211 JE Take UP Ball Bearing Unit
جديد
متوفر1 وحدةجاهز للشحن
وحدة محمل كروي Koyo UCT211 JE مع قطر محور 55 مم، هيكل من الحديد الزهر، وسعة حمل ديناميكي 43.4 كيلو نيوتن. مصممة للمتانة والمحاذاة الدقيقة.
29.443.455BallbearingCastDynamicHousingIronJEkNKoyoLoadlockingmmscrewSetshaftStaticT211Take-upUCS11UCT211Unit
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
Koyo TAKE UP BALL BEARING UNIT – UCT211 JE
The Koyo UCT211 JE is a high-performance Take-Up Ball Bearing Unit engineered for durability and reliability. This unit is ideal for applications requiring precision alignment and robust load handling. Below are the detailed specifications:
- Manufacturer: Koyo
- Type: Take-Up Ball Bearing Unit
- Model: UCT211 JE
- Housing No.: T211 JE
- Bearing No.: UCS11
- Shaft Diameter d: 55 mm
- Overall Width A: 64 mm
- Width of Inner Ring B: 55.6 mm
- Width of Piloting Groove A1: 22 mm
- Overall Height H: 146 mm
- Height of Attachment End H2: 102 mm
- Overall Length L: 171 mm
- Diameter of Attachment Bolt Hole N: 35 mm
- Length of Attachment Slot N1: 25 mm
- Height of Attachment Slot N2: 64 mm
- Length of Piloting Groove L3: 95 mm
- Basic Load Rating:
- Dynamic: 43.4 kN
- Static: 29.4 kN
- Fatigue Load Limit: 1.34 kN
- Housing Type: Take-up
- Material, Housing: Cast Iron
- Locking Device: Set Screw Locking
