Koyo UCT211 JE Take UP Ball Bearing Unit
Nouveau
En stock1 unitéPrêt à être expédié
Unité de palier à billes Koyo UCT211 JE avec un diamètre d'arbre de 55 mm, un boîtier en fonte et une capacité de charge dynamique de 43,4 kN. Conçu pour la durabilité et un alignement précis.
29.443.455BallbearingCastDynamicHousingIronJEkNKoyoLoadlockingmmscrewSetshaftStaticT211Take-upUCS11UCT211Unit
Stock massif
Expédition mondiale
Support Expert
Qualité garantie
Koyo TAKE UP BALL BEARING UNIT – UCT211 JE
The Koyo UCT211 JE is a high-performance Take-Up Ball Bearing Unit engineered for durability and reliability. This unit is ideal for applications requiring precision alignment and robust load handling. Below are the detailed specifications:
- Manufacturer: Koyo
- Type: Take-Up Ball Bearing Unit
- Model: UCT211 JE
- Housing No.: T211 JE
- Bearing No.: UCS11
- Shaft Diameter d: 55 mm
- Overall Width A: 64 mm
- Width of Inner Ring B: 55.6 mm
- Width of Piloting Groove A1: 22 mm
- Overall Height H: 146 mm
- Height of Attachment End H2: 102 mm
- Overall Length L: 171 mm
- Diameter of Attachment Bolt Hole N: 35 mm
- Length of Attachment Slot N1: 25 mm
- Height of Attachment Slot N2: 64 mm
- Length of Piloting Groove L3: 95 mm
- Basic Load Rating:
- Dynamic: 43.4 kN
- Static: 29.4 kN
- Fatigue Load Limit: 1.34 kN
- Housing Type: Take-up
- Material, Housing: Cast Iron
- Locking Device: Set Screw Locking
