Motion Control Rotary Encoders

Eltra EH63E 1B500S12P10S3MR.537 Incremental Encoder

Name: ELTRA EH63E 1B500S12P10S3MR.537 INCREMENTAL ENCODER
Brand: ELTRA
SKU: 1001202
Price: 250.00 USD
Availability: InStock

eltra-eh63e-1b500s12p10s3mr-537-incremental-encoder-1

Usado

En stock1 unidadListo para enviar

250,00$

INCREMENTAL ENCODER

Eltra EH63E 1B500S12P10S3MR.537 is a compact incremental encoder with 500 ppr resolution, 3000 rpm shaft speed, and robust IP66-rated design for industrial motion systems.

Fabricante

ELTRA

SKU

1001202

Categoría

Rotary Encoders

Condición

Usado

12V 1B500S12P10S3MR.537 500 Control EH63E Eltra Encoder Feedback Incremental Industrial IP66 Motion PPR Pull Push Sensor shaft

Inventario Masivo

Envío global

Soporte experto

Calidad Garantizada

ELTRA EH63E 1B500S12P10S3MR.537 INCREMENTAL ENCODER

The Eltra EH63E series incremental encoder is built to deliver precise position feedback in industrial automation systems. With a compact design, high resolution, and robust materials, it is an ideal choice for motion control applications.

Manufacturer: Eltra

Type: Incremental Encoder

Model: EH63E 1B500S12P10S3MR.537

Ref No.: 31869

Principle of Operation: Incremental

Body Dimension	63 mm
Version	537
Type of Flange	mod.EH-EL 63 E
Shaft Diameter	10 mm
Shaft Speed	3000 rpm
Bearings	2 Ball Bearings
Output Type	PUSH PULL
Resolution	500 ppr
Supply Voltage	12 V
Operating Temperature	0 / +60 °C
Degree of Protection	IP66
Shaft Material	Stainless Steel AISI303
Body Material	Aluminium UNI 5076
Housing Material	PA 66 reinforced with fiberglass
